Parker 6 Freeze Drying Machine

WET VOLUME 1500 LBS
The Parker 6 has a capacity of six of our heated carts, with a wet weight of 1500 lbs. Manufactured and assembled in the USA.



Parker 6 Freeze Dryer
Parker 6 Freeze Dryer
Parker 6 Freeze Dryer
Parker 6 Freeze Dryer
PARKER 6 FREEZE DRYER

Features

PARKER 6 FREEZE DRYER

Maintenance

  • Stainless steel vacuum chamber
  • Easy to operate controls
  • Aluminum carts for maximum heat exchange efficiency
  • Deep vacuum system with less frequent maintenance and repairs
  • Industry grade condenser unit designed specifically for PFD
  • High ratio of cold plate surface to capacity for quality freeze drying
  • Remote access for monitoring & troubleshooting
  • Service & wear items in stock via exclusive e-commerce store
  • Provided with comprehensive guide for maintenance intervals
  • Exclusive access to Parker University for continuing education
  • Guidance on daily, weekly, monthly, semi and annual inspections
nsf
Product Specification
Description: Imperial: Metric:
Cart Capacity 6 6
Chamber Dimension (Door Open) 300L x 84W x 100H Inches 762L x 214W x 254H cm
Refrigeration Skid Heatcraft Magna Heatcraft Magna
Refrigeration Dimensions 237 L x 50W x 60H Inches 602L x 127W x 153H cm
Pan Dimensions 26L x 18W x 1H Inches 67L x 46W x 3H cm
Maximum Heated Product Pans 252 252
Usable Shelf Area 819 Sq Ft 76 Sq m
Shelf Temp Range -50 to 180 F -45 to 82 C
Maximum Vacuum ≤ 0.01 mbar ≤ 0.01 mbar
Median Weight Capacity 1500 lbs 680 kg
Ice Condenser Capacity 2510 lbs 1138 kg
Chamber Standard Operating (dB) 85 85
Condenser Operating (dB) 85 85
Power Requirements 480V 3 Phase 480V 3 Phase
Suction Temp -60 F -51 C
Typical Max Power Usage 128 FLA  128 FLA



VALUE-ADD PRODUCT CALCULATOR

More Product. More Profit.

Enter some business metrics to find out the Parker Freeze Dry unit that suits your needs, and your estimated gross margin per pound.

Customer Support

We have a dedicated team of freeze dry experts ready to help you succeed. When you request a consultation, you are guaranteed to find the best solution for your operation.

Parker University

Exclusive content is available for operators covering maintenance, cleaning, continuing education, parts and service. Subscribe and save with automated shipping of required maintenance items at recommended intervals.
