Parker 16R Freeze Drying Machine

WET VOLUME 4000 LBS
The Parker 16-R Commercial Freeze Dryer is our largest model, built to handle a massive 4,000 lbs wet capacity with space for 16 Heated Carts. Designed for high-demand production with minimal maintenance requirements, it keeps operations running efficiently and reliably for food, pet treat, and specialty product manufacturers.
paker 16R
The unit shown in the video is the Parker 10R. The Parker 16R has the same components but offers a load capacity of 4,000 lbs. per batch.
PARKER 16R FREEZE DRYER

Features

PARKER 16R FREEZE DRYER

Maintenance

  • Stainless steel vacuum chamber
  • Easy to operate controls
  • Aluminum carts for maximum heat exchange efficiency
  • Deep vacuum system with less frequent maintenance and repairs
  • Industry grade condenser unit designed specifically for PFD
  • High ratio of cold plate surface to capacity for quality freeze drying
  • Remote access for monitoring & troubleshooting
  • Service & wear items in stock via exclusive e-commerce store
  • Provided with comprehensive guide for maintenance intervals
  • Exclusive access to Parker University for continuing education
  • Guidance on daily, weekly, monthly, semi and annual inspections
NOW AVAILABLE IN (2)
Product Specification

Description:

Imperial:

Metric:
Cart Capacity 16 16
Chamber Dimension (Door Open) 292L x 125W x 101H Inches 742L x 318W x 257H cm
Refrigeration Skid Heatcraft Magna Heatcraft Magna
Refrigeration Dimensions 230L x 88W x 60H Inches 585L x 224W x 153H cm
Pan Dimensions 26L x 18W x 1H Inches 67L x 46W x 3H cm
Maximum Heated Product Pans 672 672
Usable Shelf Area 2184 Sq Ft 202.9 Sq m
Shelf Temp Range -50 to 180 F -45 to 82 C
Maximum Vacuum ≤ 0.01 mbar ≤ 0.01 mbar
Median Weight Capacity 4000 lbs + 1184 kg +
Ice Condenser Capacity 9596 lbs 4352 kg
Chamber Standard Operating (dB) >=85 85
Condenser Operating (dB) >=85 85
Power Requirements 480V 3 Phase 480V 3 Phase
Suction Temp -60 F -51 C
Typical Max Power Usage 325 FLA 325 FLA



PRODUCT CALCULATOR

More Product. More Profit.

Enter some business metrics to find out the Parker Freeze Dry unit that suits your needs, and your estimated gross margin per pound.

Customer Support

We have a dedicated team of freeze dry experts ready to help you succeed. When you request a consultation, you are guaranteed to find the best solution for your operation.

Parker University

Exclusive content is available for operators covering maintenance, cleaning, continuing education, parts and service. Subscribe and save with automated shipping of required maintenance items at recommended intervals.
